Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt

(No reviews yet) Write a Review
SKU:
51626
MPN:
SHR-17
Condition:
New
Shipping:
Calculated at Checkout

Bulk discount rates

Below are the available bulk discount rates for each individual item when you purchase a certain amount

Buy 15 - 29 and get 10% off
Buy 30 or above and get 20% off
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
  • Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt
$33.00
Was: $75.00

Description

Uni-Solar SHR-17 17 Watt Amorphous Flexible Solar Panel Roofing Shingle - 9 Volt - Brand New Old Stock



Each Roofing Shingle covers about 3 square feet of roof area and replaces and be used where asphalt shingles are appropriate.



The Uni-Solar SHR-17 17W Solar Roofing Shingle is old stock designed in 2007.  At it's design it received multiple awards including "The Grand Award in Best of What's New in Environmental Technology" and Discover Magazine's Technical Innovation Award for Best Innovation


These are sold by the shingle and each shingle produces 17 watts of power (9 Volts at 1.9 Amps).  They were designed and textured to replace asphalt shingles as a roofing material.  Each shingle is 12 inches wide by 86.5 inches long and the 18 gauge positive and negative wires extend from the bottom of the panel.  This product consists of 12 solar cells connected within each roll.  Each of the 12 cells is 5 by 7 inches in size and produces approximately 1.4 watts (1.4 watts x 12 cells). When 2 panels are connected in series they will product 18 Volts at 3.8 amps (34 watts).  Once set, the sun's heat molds the panel adhesive together forming a weather-resistant seal.  They are designed to be an economical roofing alternative, as well as, a reliable power source.
Due to the panel flexibility they can be used for many different applications, such as: 12 Volt Battery chargers, sheds, guest houses, off grid projects and other outdoor electrical needs.

These solar roofing shingle panels are New Original Stock.

This listing is for one shingle roll (one row of solar cells).  We have also listed them in their factory carton of 15 at a discounted rate.  Refer to the specifications below, and photo sheets provided, and contact us for any additional questions!


SPECIFICATIONS:

    • Rated Power (Watts): 17
    • Max Power Point VMPP (V): 9
    • Max Power Point IMPP (A): 1.9
    • Open Circuit Voltage (Volts): 13
    • Short-Circuit Current (Amps): 2.4
    • Shingle Length (in./mm): 86.4 in./2195 mm
    • Shingle Width (in./mm): 12 in. (5 in. exposed area)/305 mm
    • Weight (lb./kg): 4.8 lb./2.2 kg
    • Customer-Supplied Substrate: Wood Deck and Fire Retardant Underlayment
    • Minimum Slope 3:12 (15 ft.)
    • Maximum Slope: 21.12 (60 ft.)


According to the Brochure Shingles Comply with the Following Qualification Tests:

    • Capable of Withstanding 80 mph Wind Speeds
    • Meets IEC 61646 Requirements
    • Thermal Cycling
    • Humidity-Freeze Test
    • Damp Heat Test
    • UV-Test
    • Wet Insulation Test
    • Mechanical Load Test
    • Hail Impact Test
    • Robustness of Terminations Test



Condition:

The Uni-Solar SHR-17 17W Solar Roofing Shingle is a New Old Stock solar shingle made in the USA in 2007. This listing is for one single shingle. We have also listed them in their factory carton of 15 at a discounted rate. Please contact us for details!
