Probes and Test Leads

Tektronix A6302 Current Probe, 50 MHz, 20A, for AM 503 Amplifiers, 11A16 Plug-in From the manufacturer: DC to 50 MHz current probe designed for use with the AM 503 family of current probe amplifiers and with the 11A16 plug-in. With the AM 503...

Tektronix Generic 1:1 Probe with Hook Attachment This probe came to us from a retiring electrical engineer who used this in his calibration and product development electronics lab.

. This Logic probe is to be used in conjunction with a unit that detects the signals and controls the lamp. The metal tip on the probe is broken, The black plastic tip, holding it, screws off and is probably easy to repair. Lamp is about 3-5 V.

Bandwidth DC to 120 MHz Attenuation: 100X Input Resistance: 10 MO Scope Input Resis: 1 MO Input Capacitance: Approx. 2.5pF Compensation Range: 8pF to 47pF Max Rated Voltage: 1.5 KV RMS Designed for use with wide-band, real-time...

10:1 10 OHM/13pF For 1M OHM/24-45pF Inputs

10:1 1M OHM/8.0 pF For 1/m OHM /9-14 pF Units

TPI MSQK-2574RO Oscilloscope Passive Probe X10
