Description
Tektronix P6137 070-6432-00 10X Passive Probe 2400 Series Instruction Sheet
This is the original printed instruction sheet for the Tektronix P6137 10X Passive Probe, published under Tektronix publication number 070-6432-00. It covers setup, operation, and specifications for the P6137 passive probe as used with Tektronix 2400 Series oscilloscopes.
Specifications & What's Included
- Manufacturer: Tektronix
- Model: P6137
- Document type: Instruction Sheet
- Publication number: 070-6432-00
- Product Group: 60
- Covers: P6137 10X Passive Probe
- Compatible with: Tektronix 2400 Series Oscilloscopes
- Format: Printed / hard copy
- Language: English
Applications
The Tektronix P6137 is a 10X passive probe designed for use with Tektronix 2400 Series oscilloscopes, a family of portable and benchtop instruments produced from the mid-1980s onward. This instruction sheet provides the reference documentation that ships with the probe — covering connection, compensation, operating precautions, and specifications. It is useful for technicians and engineers who are bringing a P6137 probe back into service, verifying specifications, or replacing a lost original document. Tektronix 2400 Series scopes and their associated probes remain in active use in electronics labs, educational settings, and service departments that maintain legacy Tektronix equipment.
This Tektronix P6137 10X Passive Probe Instruction Sheet (pub no. 070-6432-00) is in good used condition with normal shelf wear on the cover. All pages appear present and legible. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Tektronix |
Model: |
P6137 |
MPN: |
070-6432-00 |
Type: |
Instruction Sheet |
SKU: |
37696 |
Document Type: |
Instruction Sheet |
Publication Number: |
070-6432-00 |
For Use With / Compatible With: |
Tektronix P6137 10X Passive Probe |
Compatible With: |
Tektronix 2400 Series Oscilloscopes |
Product Group: |
60 |
Language: |
English |
Format: |
Printed |
Seller Notes: |
Instruction sheet only — no probe or accessories included. |
Country/Region of Manufacture: |
United States |
Condition Notes: |
This Tektronix P6137 Instruction Sheet (pub no. 070-6432-00) is in good used condition with normal shelf wear. All pages are present and legible. Please contact us with any questions. |
