Tektronix

Tektronix 7A24 070-2391-00 Dual Trace Amplifier Instruction Manual SN B103000-UP

(No reviews yet) Write a Review
SKU:
28606
MPN:
070-2391-00
Condition:
Used
Availability:
Currently out of stock — contact us for availability.
Weight:
1.00 LBS
Shipping:
Calculated at Checkout
  • Tektronix 7A24 Dual Trace Amplifier Instruction Manual 070-2391-00 — front cover, spiral-bound with blue Tektronix cover
  • Tektronix 7A24 Dual Trace Amplifier Instruction Manual title page showing SN B103000-UP, First Printing Sep 1977, Revised Jun 1988
  • Tektronix 070-2391-00 manual interior page showing Tektronix Inc. Beaverton Oregon address and Product Group 42 designation
$16.50
Was: $35.00

This item is temporarily unavailable. Please view our recommended, in-stock alternatives directly below.

Description

Tektronix 7A24 070-2391-00 Dual Trace Amplifier Instruction Manual SN B103000-UP

This is the original Tektronix Instruction Manual for the 7A24 Dual Trace Amplifier plug-in, publication number 070-2391-00. It covers units with serial numbers B103000 and above, first printed in September 1977 and revised in June 1988. The manual provides complete operating, theory, and service information for the 7A24 amplifier plug-in module.

Specifications & What's Included

  • Manufacturer: Tektronix, Inc., Beaverton, Oregon
  • Publication Number: 070-2391-00
  • For: Tektronix 7A24 Dual Trace Amplifier
  • Serial Number Coverage: SN B103000-UP
  • Document Type: Instruction Manual
  • First Printing: September 1977
  • Revision: June 1988
  • Product Group: 42
  • Format: Spiral-bound hardcopy, English language
  • Includes: Manual only

Applications

The Tektronix 7A24 is a dual-trace vertical amplifier plug-in designed for use with Tektronix 7000-series oscilloscope mainframes — a modular platform that was the industry standard for general-purpose and laboratory oscilloscope work from the late 1960s through the 1980s. The 7000 series accepted interchangeable plug-in amplifiers and time bases, allowing engineers and technicians to configure the instrument for a wide range of measurement tasks. The 7A24 specifically provided two independent input channels with selectable coupling and deflection sensitivity, making it a workhorse plug-in for electronics development, production testing, and field service during that era. This manual covers theory of operation, calibration procedures, and component-level service information — exactly what is needed by technicians maintaining or restoring 7A24-equipped systems today. Collectors and vintage instrument enthusiasts restoring 7000-series scopes also frequently seek original Tektronix documentation of this type.

Condition: Used
This Tektronix 7A24 Dual Trace Amplifier Instruction Manual (070-2391-00) is in good used condition. The spiral binding is intact, and all pages appear present and legible. The cover shows light shelf wear consistent with age — minor scuffing and slight yellowing at the edges, as visible in the photos. There are no torn, missing, or water-damaged pages noted. Please view our photo set and contact us if you have any questions.
View AllClose

Warranty Information

We stand behind every item we sell with a 30-day money-back guarantee. If your item arrives not as described, you may return it within 30 days for a full refund. Please inspect your purchase upon arrival and contact us with any questions.
View AllClose

Additional Information

Brand:
Tektronix
Model:
7A24
MPN:
070-2391-00
Type:
Instruction Manual
SKU:
28606
Document Type:
Instruction Manual
For Make/Model:
Tektronix 7A24 Dual Trace Amplifier
Serial Number Range:
SN B103000-UP
Publication Number:
070-2391-00
Edition/Revision:
Revised June 1988
First Printing:
September 1977
Compatible With:
Tektronix 7000-series oscilloscope mainframes
Language:
English
Format:
Print / Hardcopy
Country/Region of Manufacture:
United States
Seller Notes:
Manual only.
Condition Notes:
This Tektronix 7A24 Dual Trace Amplifier Instruction Manual (070-2391-00) is in good used condition. Binding is intact, all pages present and legible. Cover shows light shelf wear. Please contact us with any questions.
View AllClose
