Description
Medical Graphics MedGraphics PF/Dx 801075-001 Pulmonary Function System Rev B
The MedGraphics PF/Dx is a pulmonary function testing (PFT) system manufactured by Medical Graphics Corporation (MGC). It is designed to measure and analyze lung function parameters including spirometry, flow-volume loops, and related respiratory diagnostics. The system is built on a mobile cart platform with a vertical tower column and a pivoting arm/tray assembly that houses the pneumatic measurement components. This unit is Model 801075-001, Revision B, and is compatible with MedGraphics BreezeSuite 5.1 pulmonary function testing software.
Specifications & What's Included
- Manufacturer: Medical Graphics Corporation (MGC)
- Model: 801075-001
- Revision: Rev B
- Product Line: PF/Dx (Pulmonary Function / Diagnostics)
- Compatible Software: MedGraphics BreezeSuite 5.1 Pulmonary Function Testing Software
- Form Factor: Mobile wheeled cart with vertical tower column and pivoting tray arm
- Internal Pump: ULVAC Sinku Kiko vacuum diaphragm pump (visible in base compartment)
- Tray Assembly: Houses pneumatic manifold, solenoid valves, T-connector assembly, and internal tubing
- Base: Four-wheel caster base with teal accent stripe
- Power: IEC inlet visible on base rating plate
- Tubing/Pneumatic connections present and visible
Applications
The MedGraphics PF/Dx is a clinical pulmonary function testing platform used in respiratory medicine, pulmonology clinics, hospitals, and occupational health settings. PFT systems of this type measure key lung function parameters — spirometry values (FVC, FEV1, FEV1/FVC), flow-volume loops, and related indices — to aid in diagnosing and monitoring conditions such as asthma, COPD, emphysema, and restrictive lung disease. Medical Graphics Corporation (MGC), based in St. Paul, Minnesota, has been a leading manufacturer of cardiopulmonary diagnostic equipment since the 1970s; the PF/Dx line represents their mid-range mobile PFT platform designed for clinical environments where portability and ease of setup are priorities. These systems interface with dedicated PFT software (in this case BreezeSuite) running on a connected PC, which handles data acquisition, test protocol management, and report generation. This type of equipment is found in pulmonology practices, hospital respiratory therapy departments, university medical centers, and occupational medicine clinics.
This Medical Graphics MedGraphics PF/Dx Pulmonary Function System (Model 801075-001, Rev B) was pulled from a working clinical environment where it had been in active use. The unit has been visually inspected and photographed throughout, including the interior tray assembly and base pump compartment. The white housing shows typical wear from clinical use. The ULVAC Sinku Kiko pump is present and visible in the base compartment, and all pneumatic tubing, the arm/tray assembly, and internal manifold components appear intact. The system has not been powered up or tested at our facility. Please review all photos carefully and contact us with any questions before purchasing.
Thanks for your interest. Recycled Goods Inc., Ventura, CA.
FDA Regulation and Certification: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not purchase this item unless you are an authorized purchaser. If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping.
Upon receipt, it is the BUYER'S responsibility to have this instrument checked and certified for use by a qualified Technician prior to placing it into use or service.
Warranty Information
Additional Information
Brand: |
Medical Graphics Corporation |
Model: |
801075-001 |
MPN: |
801075-001 |
Secondary Model: |
PF/Dx |
Revision: |
Rev B |
Type: |
Pulmonary Function Testing System |
SKU: |
10916 |
Compatible Software: |
MedGraphics BreezeSuite 5.1 |
Application: |
Pulmonary Function Testing (PFT), Spirometry |
Form Factor: |
Mobile Cart / Wheeled Stand |
Pump: |
ULVAC Sinku Kiko diaphragm/vacuum pump |
Seller Notes: |
System includes wheeled cart base, column, arm/tray assembly, and pneumatic tubing. |
Country/Region of Manufacture: |
United States |
Condition Notes: |
This Medical Graphics MedGraphics PF/Dx 801075-001 Pulmonary Function System was pulled from a working clinical environment. Not powered or tested at our facility. Visually inspected — housing shows typical wear, internal components appear intact. |
California Prop 65 Warning: |
WARNING: This product can expose you to chemicals including lead and lead compounds, and DEHP (a phthalate), which are known to the State of California to cause cancer and birth defects or other reproductive harm. Go to P65Warnings.ca.gov |
