Description
Voltage Nominal 120V (-25% +15%) w/o battery Waveform Pure Sinewave with <5% THD Current 6 to 12 Amps Depending on Model and Load Voltage 115V +/-3% Frequency 50/60Hz Autoselect +/-3% (Programmable) Frequency Synched to Utility Crest factor 3 to 1 Inrush current Up to 500% for 0.3 sec Transfer Time ZERO Surge Protection 480 Joules Lightning Protection 6500A, ANSI C62.41/IEEE 587 A& B Model and Power Ratings (All available in the same enclosure) Model Output Power Weight Net/Shipping IQ-650 650VA/433W 5.6Amp 39/45 lbs IQ-800 800VA/533W 7.0Amp 41/47 lbs IQ-1100 1100VA/733W 9.7Amp 48/54 lbs Physical Specifications Dimensions 16W x 3.5H x 17D - Horizontal or 3.5W x 16H x 17D as Tower Temperature 0 to 40C Humidity 0% to 95% Non-Condensing RS232 Baud Rates 1200, 2400, 4800, 9600B (selectable) Power Connections Six Output receptacles Enclosure Color Beige is Standard Agencies UL Listed, FCC Compliant
