Description
IBM 72X5641 V.35 Cable Assembly 9404 9020 AS/400 System/36 EC E39307
The IBM 72X5641 is an original V.35 cable assembly designed for use with IBM midrange systems including the 9404 AS/400 and 9020. It connects V.35 WAN interface devices — such as DSU/CSU units or synchronous modems — to the communications adapter in these IBM systems, providing the physical layer link for synchronous serial data communications.
Specifications & What's Included
- Manufacturer: IBM
- Part Number: 72X5641
- EC Number: E39307
- Secondary Model Reference: 9020
- Interface: V.35
- Connector End 1: DB-25 female (D-sub 25-pin)
- Connector End 2: V.35 Winchester-style MRAC connector with gold pins
- Cable jacket: Dark gray, multi-conductor
- Country of Manufacture: Mexico
- Manufacture Date: September 29, 1997
- Compatible systems: IBM 9404 AS/400, IBM 9020
Applications
The IBM 9404 was a mid-range AS/400 server from the late 1980s and 1990s, widely used in business environments for database-driven applications running IBM's OS/400 operating system. The V.35 interface was the standard electrical specification for synchronous serial WAN connections at speeds from 48 Kbps up to 2 Mbps during this era, commonly used to connect the AS/400's communications adapter to a T1 or fractional-T1 DSU/CSU for wide-area networking. The IBM 9020 refers to a specific feature or model designation within this system family. V.35 cables like this one remain in demand today for organizations still maintaining legacy IBM midrange systems, as well as for lab environments testing and servicing period-correct equipment. The DB-25 to V.35 Winchester cable configuration was a standard IBM wiring approach for this class of WAN interface hardware.
This IBM 72X5641 V.35 Cable Assembly has been inspected and is in good used condition. The cable jacket is intact with no cuts or kinks, and both connectors — the DB-25 female end and the V.35 Winchester-style pin end — appear clean and undamaged with all pins present. Normal surface scuffing and minor handling marks are visible on the connectors and jacket, consistent with prior use. Please view our photo set and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
IBM |
Model: |
72X5641 |
MPN: |
72X5641 |
Secondary Model: |
9020 |
EC Number: |
E39307 |
Type: |
V.35 Cable Assembly |
Interface: |
V.35 |
Compatible With 1: |
IBM 9404 AS/400 |
Compatible With 2: |
IBM 9020 |
Compatible With 3: |
IBM System/36, System/38 |
Connector End 1: |
DB-25 Female (D-sub 25-pin) |
Connector End 2: |
V.35 Winchester / MRAC 34-pin style |
Country/Region of Manufacture: |
Mexico |
Manufacture Date: |
09/29/1997 |
SKU: |
40041 |
Seller Notes: |
Cable only — no additional accessories included. |
Condition Notes: |
This IBM 72X5641 V.35 Cable Assembly has been inspected and is in good used condition. Both connectors are intact with all pins present. Minor surface scuffing consistent with prior use. |
