Hughes 9040H02R002 5.9-6.4 GHz 40 Watt C-Band TWTA Traveling Wave Tube Amplifier
The Hughes Aircraft 9040H02R002 is a C-Band traveling wave tube amplifier (TWTA) designed for satellite uplink earth station service. Built by Hughes Aircraft Company's Electron Dynamics Division — one of the foremost manufacturers of traveling wave tubes and amplifiers for satellite and defense applications — this unit covers the standard C-Band uplink frequency range of 5.925 to 6.425 GHz at a continuous output power of 40 watts. It is housed in a rackmount chassis and accepts standard 120V AC line power.
Specifications & What's Included
- Manufacturer: Hughes Aircraft Company, Electron Dynamics Division
- Model: 9040H02R002
- Type: C-Band Traveling Wave Tube Amplifier (TWTA)
- Frequency Range: 5.925 to 6.425 GHz (C-Band uplink)
- Output Power: 40 Watts
- Input Power: 120V AC, 60 Hz, 3A
- Form Factor: Rackmount chassis
- RF Input Connector: SMA with attenuator adjustment (AT. ADJ.)
- RF Output Interface: Rectangular waveguide flange
- Front Panel Controls: POWER and RF toggle switches, POWER ON / READY RF ON status indicators, Helix Current analog meter
- Rear Panel: F1 and F2 rotary fuse holders, J1 IEC AC power inlet
- Internal TWT Tube: Hughes 670 HA type (Ef 7.6V, Ik 91.6 mA, Ek −3.60 kV, Eb −1.80 kV, Ea 400V; mfg. date 1984 week 42)
- Internal Waveguide Filter: UTE Microwave Inc. CWA-4649-TT
- Includes: Amplifier unit only — no cables, rack hardware, or documentation
Applications
Traveling wave tube amplifiers in the C-Band uplink range (5.925–6.425 GHz) are used in fixed satellite service (FSS) earth station transmit chains. The TWTA is the primary high-power amplification stage between the upconverter output and the antenna feed, taking a low-level modulated IF/RF signal and amplifying it to the power level needed to drive a parabolic dish antenna and maintain a reliable link budget to a geostationary satellite. Hughes Aircraft's Electron Dynamics Division was a leading TWT and TWTA manufacturer from the 1960s through the 1980s, supplying amplifiers for commercial broadcast, telecommunications, and government satellite ground stations. C-Band satellite communication was the dominant commercial satellite band throughout the 1970s and 1980s, used extensively for television distribution, telephony backhaul, and VSAT data networks. These amplifiers were typically deployed in outdoor antenna-mounted or indoor rack-mounted configurations at teleport facilities, broadcast uplink sites, corporate VSAT hubs, and military satellite terminals. C-Band earth station infrastructure continues to be maintained and operated at many facilities today, and Hughes TWTAs from this era remain in active service as well as sought after for spares and repairs.
This Hughes 9040H02R002 C-Band Traveling Wave Tube Amplifier has been visually inspected and appears to be in good used condition. It has not been powered up or bench-tested at our facility. The chassis and panels show normal wear consistent with prior service use, and the front-panel controls, indicators, and connectors appear intact. The internal TWT tube (670 HA, mfg. 1984) and associated circuitry are visible in our photos and appear undisturbed. Please review our complete photo set carefully before purchasing, and contact us if you have any questions.
Warranty Information
Additional Information
Brand: |
Hughes Aircraft |
Model: |
9040H02R002 |
MPN: |
9040H02R002 |
Type: |
Traveling Wave Tube Amplifier (TWTA) |
SKU: |
39949 |
Frequency Range: |
5.925 to 6.425 GHz |
Frequency Band: |
C-Band |
Output Power: |
40 Watts |
Input Power: |
120V AC, 60 Hz, 3A |
Form Factor: |
Rackmount |
RF Input Connector: |
SMA |
RF Output Interface: |
Rectangular Waveguide Flange |
Application: |
Satellite Uplink / Earth Station C-Band |
TWT Tube Type: |
670 HA |
TWT Tube Manufacture Date: |
1984 (Week 42) |
Internal Waveguide Filter: |
UTE Microwave CWA-4649-TT |
Manufacturer Division: |
Hughes Aircraft Electron Dynamics Division |
Country/Region of Manufacture: |
United States |
Seller Notes: |
Amplifier unit only — no cables, documentation, or rack hardware included. |
Condition Notes: |
This Hughes 9040H02R002 C-Band TWTA has been visually inspected and appears to be in good used condition. Not powered or bench-tested at our facility. Controls and connectors appear intact. Please view photos and contact us with questions. |
